Malt mill with 2 rollers and wooden base

Category: Mills
Product code: ABP0254
Product available
We are sorry, for this order you will receive a quotation for shipping costs
Qty € 126.00
Add to cart

Malt mill with 2 rollers and wooden base

Wooden base made of high quality meranti plywood that guarantees stability and resistance. Complete with screws for the mill tightening and grommets to be screwed under the base, to be positioned according to the size of the bucket (NOT INCLUDED). The two-roller manual mill SMART is suitable for grinding barley malt, ideal for the production of beer with all-grain method, and today, thanks to the wooden support base, can be placed on a bucket to avoid that powders expand into the work environment.

Adjustable knurled rollers, made of stainless steel with a large aluminum hopper to have an optimal grinding of all types of malt, from the most friable to the hardest.

It is equipped with a handy manual handle, or connectable to a normal electric drill.

Technical characteristics of the Smart malt mill

  • Manual model
  • Production capacity: up to 70 kg/h
  • Hopper dimensions mm 210 x 225 x 220 h
  • Total height mm 270
  • Base height mm 50
  • Wooden base: 380 x 480 x 10 h
  • Rollers size: length mm 126 - diameter mm 32
  • Roller adjustment in mm: from 0.6 to 2.5 (0.1 to 0.025" - inches) - to adjust the distance turn the eyelets and tighten the nut.
  • Use a brush to clean the rollers.

The product is supplied pre-assembled, as the base is already assembled, but you will have to assemble the hopper and screw it onto the wooden base, this easy operation should be carried out with the help of a Phillips screwdriver (short) and pliers.

Technical description
  • manual model
  • to clean the rollers use a brush.
