60 HL stainless steel peristaltic electric pump

60HL PERISTALTIC PUMP FOR LIQUIDS ONLY WITH RADIO CONTROL KIT

Complete of:

• AISI 304 stainless steel trolley with wheels equipped with locking device
• Pump body in AISI 304 stainless steel
• Rotor with two rollers mounted on adjustable pressure bearings
• Peristaltic hose in food grade rubber with TCA-TBA and FDA certification
• Double expansion tank
• Electrical panel with reverse voltage 400V / 3HP / 50HZ
• Electronic speed variator (inverter)
• Control wire and reverse gear system (10 MT.)
• Options included:
• Radio control kit

Characteristics:

• engine revolutions per minute (rpm): 19/63
• liquid flow rate (hl/h): 10/60
• DIN 50 fittings
• engine power kW: 1.5
• peristaltic tube: Ø 45 mm
• number of rollers: 2
• power supply: three-phase 400V
• length mm: 1050
• depth mm: 650
• height mm: 900
• weight kg: 120
