2,5 HP Elliptical Piston Electric Wine Pump
Code: EPP0211
Brand: Polsinelli
€ 4331.97
Ready to order product
Shipping within 29 working days (from Monday to Friday) from the receipt of payment.
Shipping costs:
Free shipping to Italy
Add to favorites
Description
2,5 HP Elliptical Piston Electric Wine Pump
The elliptical rotor pump has an AISI 304 stainless steel body and is used to transfer grapes and wine marc. The latter gets placed in the hopper, where it is pushed outwards by the elliptical rotor via an Ø 80 mm hose for garpes and wine marc or destemmed grapes. It is equipped with an electric panel, loading hopper with deeding screw, trolley with wheels and safety grille.
Characteristics:
- Stainless steel rotor
- Three-phase 380 V, 50 Hz, 2.5 HP electric motor (single-phase 220V on request).
- Throughput of whole grapes, crushed grapes and destemmed grapes: 6-8 t/h
- Grape marc flow rate: 5-7 t/h
- Clamp connection nominal diameter 80
- Compensation chamber
- Technical description
- Power: 1,85 kW
- Hose connector Ø 80 mm
- Head MT 3
- Discharge distance mt 10
- Overall dimensions: mm 600x700x900
- Weight: 100 Kg
